Maytag Bravos XL Washer Error Codes
Once you put your Maytag Bravos washer into diagnostic Mode, the washer may display some fault codes depending on what has failed (what you need to check).
Below is a list of the most common Maytag Bravos washer error codes to point you in the right direction when troubleshooting your Maytag Bravos washer
Table of Contents
Maytag Bravos XL Washer Error Codes – meaning and troubleshooting steps
Error code F0E2
Meaning: Oversuds detected, and also the washer is unable to fix the problem automatically
Recommended troubleshooting procedure
Change to HE detergent (as recommended).
Stop putting too much detergent- the issue can occur due to excessive detergent usage.
Check the pressure hose connection (from the tub to the main control)- you want to see if the hose is pinched/kinked/plugged/leaking air (and fix it depending on what you notice).
Check the basket and the drive mechanism for mechanical friction (perhaps you’ll find some cloth items between the basket and the tub).
Error code F0E3
Meaning: Overloading detected (a load size bigger than the washer’s capacity detected OR basket cannot turn)
Recommended troubleshooting procedure
Remove excess laundry and then restart the wash cycle.
Check the basket and the drive mechanism for mechanical friction (perhaps you’ll find some cloth items between the basket and the tub).
Error code F0E4
Meaning: Spin limited fault due to the water temperature is too high for a proper spin.
Recommended troubleshooting procedure
Check if the water valve is functioning correctly.
Error code F0E5 or “OFB.”
Meaning: Off-balance load detected
Error code F1E1
Meaning: Main Control fault.
Recommended troubleshooting procedure
Test and replace the main control (ACU), if needed
Error code F1E2
Meaning: There is a fault in the Main Control segment of the main control (motor or drive system issues).
Recommended troubleshooting procedure
Inspect/test the wiring connection to the motor (and the motor) itself and repair it. The motor or drive may need to remain replaced.
Error code F2E1
Meaning: UI Stuck Button (the user interface is sensing a stuck button during Diagnostic Mode)
Recommended troubleshooting procedure
Inspect ALL buttons and try to make any that appear stuck unstuck.
Run UI Diagnostic Test Mode
Error code F2E3
Meaning: UI Mismatch (machine main control or the user interface part number does not match expected values)
Recommended troubleshooting procedure
Ensure compatible ACU and UI remain installed- order correct part numbers.
Error code F2E4
Meaning: UI Software Error (Incompatible Parameter File)- a parameter file (in the UI) is incorrect.
Recommended troubleshooting procedure
Replace the entire UI.
Error code F2E5
Meaning: UI Software Error (invalid memory parameter)- a parameter file (in the UI) is corrupt
Recommended troubleshooting procedure
Replace the entire UI.
Error code F3E1
Meaning: Pressure Fault (out-of-range pressure signal detected)
Recommended troubleshooting procedure
Check the pressure hose connection (from the tub to the main control)- you want to see if the hose is pinched/kinked/plugged/leaking air (and also fix it depending on what you notice).
Check water level sensing parts/components, especially the pressure transducer.
Error code F3E2
Meaning: Inlet water temp problem (inlet thermistor has remained detected as open or shorted).
Check hot and cold water valves- confirm if cold and also hot water remains dispensed.
Replace the main control
Error code F4E1
Means: Heater is stuck ON(when it’s supposed to be OFF)
Recommended troubleshooting procedure
Test if the heater is operating properly- test the resistance of heater element (abnormal=infinity).
Error code F4E2
Meaning: When the heater is turned ON, it is not Turning On(the control is not able to detect the heater is turned ON)
Recommended troubleshooting procedure
Test if the heater is operating properly- test the resistance of heater element (abnormal=infinity).
Error code F5E1
Meaning: Lid switch fault (the lid is in lock state, but the lid switch is opened).
Recommended troubleshooting procedure
Perform Lid Lock test (under Service Test diagnostic Mode) and troubleshoot according to the error code
Measure Lid Lock Resistance(and replace the lid lock if necessary)
Error code F5E2
Meaning: Lid Lock won’t lock or it has failed completely
Recommended troubleshooting procedure
Check the lid for interference.
Check for possible lock interference with the lid or the lock bezel.
Also check if wash media buildup could be preventing lock bolt from properly extending.
Perform Lid Lock test (under Service Test diagnostic Mode) and also troubleshoot according to the error code
Measure Lid Lock Resistance(and also replace the lid lock if necessary)
